• 2nd & 3rd row coat hooks
• Analog instrumentation-inc: voltmeter, oil pressure, water temp, tachometer
• Assist handles-inc: color-keyed (2) front passengers, (2) second row
• Audiophile AM/FM stereo w/6-disc in-dash CD changer-inc: clock, (7) speakers including subwoofer, 340-watt amp, speed-compensated volume, RDS, partitioned audio, MP3 capability
• Black instrument panel-inc: cigarette lighter, pwr point w/cap, auxiliary audio input jack
• Cargo area pwr point
• Color-keyed cloth headliner
• Color-keyed cloth sunvisors w/auxiliary visors, dual illuminated mirrors
• Color-keyed floor carpeting
• Color-keyed leather-wrapped steering wheel-inc: audio, cruise & climate controls
• Concealed antenna in RH quarter glass
• Cruise control
• Cup holders-inc: (2) front/(2) rear in front console, (2) door trim panels, (3) rear quarter trim panels
• Dual zone electronic automatic temp control air conditioning w/auxiliary climate controls & exterior temp read out
• Electrochromic rearview mirror
• Front/rear door map pockets
• Full-length overhead console-inc: map lights, sunglasses holder, conversation mirror
• Head restraints at all outboard seating positions
• Leather 2nd row 40/20/40 split bench seat-inc: sliding center portion, recline, fold flat feature, carpeted seatbacks
• Lights-inc: glove box, front door approach, front dome/map, rear cargo, 2nd row map lights, illuminated entry, theater lighting
• Message center-inc: million mile odometer, trip odometer, average fuel economy, distance to empty, trip elapsed time, outside temp, compass, message center warnings, check gauges
• Pwr accessory delay
• Pwr door locks-inc: auto lock
• Pwr windows w/driver one-touch-down
• Rear seat heat ducts
• Rear window defogger
• Remote keyless entry w/(2) key fobs, illuminated entry, keypad
• SecuriLock passive anti-theft system
• Tilt steering column
• Tire pressure monitoring system (TPMS)

• 150-amp alternator
• 17" spare tire w/steel wheel
• 3.31 axle ratio
• 4-wheel pwr disc brakes w/anti-lock & brake assist
• AdvanceTrac w/roll stability control (RSC)
• Chrome-tipped exhaust
• Double wishbone front suspension w/coil-over shock
• Front skid plates
• Front/rear stabilizer bars
• Independent multi-link rear suspension
• Integrated Class IV trailer towing receiver-inc: 4-pin connector
• Maintenance-free battery w/battery saver feature
• Rear wheel drive
• Variable assist pwr rack & pinion steering w/cooler

• 3-point seat belts in rear outboard seating positions
• 4-wheel pwr disc brakes w/anti-lock & brake assist
• Adaptive stroking steering column
• AdvanceTrac w/roll stability control (RSC)
• Beltminder system
• Child safety locks on rear doors
• Front 3-point seat belts-inc: adjustable shoulder harness, load limiting retractors, pretensioners, usage sensors
• LATCH system on rear outboard seats
• Personal safety system-inc: crash severity sensor, dual-stage front airbags, driver seat position sensor
• Safety Canopy
• Side intrusion door beams
• Side thorax air bags

Safety@Front 3-Point Seat Belts

• Adjustable Shoulder Harness
• Load Limiting Retractors
• Pretensioners
• Usage Sensors

Safety@Personal Safety System

• Crash Severity Sensor
• Dual-Stage Front Airbags
• Driver Seat Position Sensor

Additional Packages

• Safety@3-Point Seat Belts In Rear Outboard Seating Positions
• Safety@4-Wheel Pwr Disc Brakes W/Anti-Lock & Brake Assist
• Safety@Adaptive Stroking Steering Column
• Safety@Advancetrac W/Roll Stability Control (Rsc)
• Safety@Beltminder System
• Safety@Child Safety Locks On Rear Doors
• Safety@Latch System On Rear Outboard Seats
• Safety@Safety Canopy
• Safety@Side Intrusion Door Beams
• Safety@Side Thorax Air Bags

• 3.31 Axle Ratio
• GVWR: 7
• 400 lbs Payload Package
• 18" x 8.5" Machined Aluminum Wheels
• AM/FM Audiophile Stereo w/In-Dash 6-CD
• 4-Wheel Disc Brakes
• Premium audio system: Audiophile
• Compass
• 7 Speakers
• Speed-Sensitive Wipers
• Auto-dimming Rear-View mirror
• Front beverage holders
• Variably intermittent wipers
• Turn signal indicator mirrors
• Trip computer
• Traction control
• Tilt steering wheel
• Steering wheel mounted audio controls
• Steering wheel mounted A/C controls
• Split folding rear seat
• Speed-sensing steering
• Speed control
• Roof rack: rails only
• Remote keyless entry
• Rear window wiper
• Rear window defroster
• Rear reading lights
• Rear audio controls
• Rear anti-roll bar
• Rear air conditioning
• Radio data system
• Power windows
• Power steering
• Power driver seat
• Power door mirrors
• Passenger vanity mirror
• Passenger door bin
• Panic alarm
• Overhead console
• Overhead airbag
• Outside temperature display
• Occupant sensing airbag
• Memory seat
• Low tire pressure warning
• Leather steering wheel
• Illuminated entry
• Heated door mirrors
• Fully automatic headlights
• Front reading lights
• Front fog lights
• Front dual zone A/C
• Front anti-roll bar
• Four wheel independent suspension
• Dual front side impact airbags
• Dual front impact airbags
• Driver vanity mirror
• Driver door bin
• Delay-off headlights
• CD player
• Bumpers: body-color
• Brake assist
• Automatic temperature control
• Alloy wheels
• AM/FM radio
• ABS brakes
• 3rd row seats: split-bench
• Voltmeter
• Tachometer
• Front Center Armrest
• Front Bucket Seats
• Electronic Stability Control
• Air Conditioning
• Rear Wheel Drive
• Tow Hitch
• Conventional Spare Tire
• Aluminum Wheels
• Power Steering
• Running Boards/Side Steps
• Automatic Headlights
• Fog Lamps
• Heated Mirrors
• Power Mirror(s)
• Integrated Turn Signal Mirrors
• Mirror Memory
• Privacy Glass
• Variable Speed Intermittent Wipers
• Power Driver Seat
• Leather Seats
• Bucket Seats
• Driver Adjustable Lumbar
• Seat Memory
• Rear Bench Seat
• 3rd Row Seat
• Rear Seat Audio Controls
• Floor Mats
• Steering Wheel Audio Controls
• Leather Steering Wheel
• Adjustable Steering Wheel
• Trip Computer
• Keyless Entry
• Immobilizer
• Climate Control
• Multi-Zone A/C
• A/C
• Rear A/C
• Rear Defrost
• AM/FM Stereo
• CD Changer
• CD Player
• Premium Sound System
• MP3 Capability
• Auxiliary Audio Input
• Auto-Dimming Rearview Mirror
• Driver Vanity Mirror
• Passenger Vanity Mirror
• Driver Illuminated Vanity Mirror
• Passenger Illuminated Visor Mirror
• Rear Reading Lamps
• Front Head Air Bag
• Front Side Air Bag
• Child Safety Locks

• Vehicle
• Rear Door Type: Liftgate
• Mileage
• EPA Fuel Economy Est - City (MPG): 12
• EPA Fuel Economy Est - Hwy (MPG): 18
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 650
• Maximum Alternator Capacity (amps): 150
• Maximum Alternator Watts: 2250
• Cooling System
• Total Cooling System Capacity (qts): 13
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3500
• Gross Axle Wt Rating - Rear (lbs): 4250
• Curb Weight - Front (lbs): 2741
• Curb Weight - Rear (lbs): 2808
• Gross Vehicle Weight Rating Cap (lbs): 7400
• Gross Combined Wt Rating (lbs): 11800
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 6000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 600
• Suspension
• Suspension Type - Front: Double Wishbone
• Suspension Type - Rear: Multi-Link
• Spring Capacity - Front (lbs): 3500
• Spring Capacity - Rear (lbs): 4250
• Axle Type - Front: Independent
• Axle Type - Rear: Independent
• Axle Capacity - Front (lbs): 3500
• Axle Capacity - Rear (lbs): 4250
• Axle Ratio (:1) - Rear: 3.31
• Shock Absorber Diameter - Front (mm): 34.9
• Shock Absorber Diameter - Rear (mm): 34.9
• Stabilizer Bar Diameter - Front (in): 1.4
• Stabilizer Bar Diameter - Rear (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.0 x - TBD -
• Rear Brake Rotor Diam x Thickness (in): 13.5 x - TBD -
• Tires
• Front Tire Order Code: T5N
• Rear Tire Order Code: T5N
• Front Tire Size: P265/70R17
• Rear Tire Size: P265/70R17
• Spare Tire Size: P265/70R17
• Front Tire Capacity (lbs): 2305
• Rear Tire Capacity (lbs): 2305
• Spare Tire Capacity (lbs): 2305
• Revolutions/Mile @ 45 mph - Front: 654
• Revolutions/Mile @ 45 mph - Rear: 654
• Revolutions/Mile @ 45 mph - Spare: 654
• Wheels
• Front Wheel Size (in): 17 x 8.0
• Rear Wheel Size (in): 17 x 8.0
• Spare Wheel Size (in): 17 x 8.0
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Variable Pwr Rack & Pinion
• Steering Ratio (:1), On Center: 20
• Turning Diameter - Curb to Curb (ft): 40.83
• Turning Diameter - Wall to Wall (ft): 42.16
• Frame
• Frame Type: Fully Boxed
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 28
• Fuel Tank Location: Midship
• Doors
• Side Door Type: - TBD -
• Exterior Dimensions
• Wheelbase (in): 119.0
• Length, Overall w/rear bumper (in): 206.5
• Width, Max w/o mirrors (in): 78.8
• Height, Overall (in): 77.2
• Overhang, Front (in): 39.2
• Overhang, Rear w/bumper (in): 48.3
• Ground to Top of Load Floor (in): 34.4
• Ground Clearance, Front (in): 8.7
• Ground Clearance, Rear (in): 8.7
• Rear Door Opening Height (in): 34.6
• Rear Door Opening Width (in): 56.7
• Side Door Opening Height (in): - TBD -
• Side Door Opening Width (in): - TBD -
• Step Up Height - Front (in): - TBD -
• Step Up Height - Side (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Console (in): - TBD -
• Cargo Area Length @ Floor to Seat 1 (in): 82.5
• Cargo Area Length @ Floor to Seat 2 (in): 44.4
• Cargo Area Length @ Floor to Seat 3 (in): 13.1
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 49.2
• Cargo Box (Area) Height (in): - TBD -
• Cargo Volume to Seat 1 (ft³): 108.3
• Cargo Volume to Seat 2 (ft³): 55.0
• Cargo Volume to Seat 3 (ft³): 18.6
• Interior Dimensions
• Passenger Capacity: 8
• Front Head Room (in): 39.6
• Front Leg Room (in): 41.1
• Front Shoulder Room (in): 63.2
• Front Hip Room (in): 60.2
• Second Head Room (in): 39.8
• Second Leg Room (in): 39.1
• Second Shoulder Room (in): 63.7
• Second Hip Room (in): 59.9
• Third Head Room (in): 38.3
• Third Leg Room (in): 37.7
• Third Shoulder Room (in): 51.9
• Third Hip Room (in): 50.2
• Summary
• Vehicle Name: Ford Expedition
• Body Style: 4 Door
• Body Code: 119" WB
